TECHNICAL DATA (BT-6) | |
Machine speed | Max. 40 Stroke/min |
Film/foil width | Max. 250mm |
Film/foil advance | Max. 180mm |
Effective surface | 242 x 167mm |
Forming depth | 25mm |
Power consumption | 10 KVA |
Electric connection | AC380V, 50/60Hz, 3-Phase |
Air consumption | 250 NL/min |
Air pressure | 6 kgf/cm² |
Net weight | 2,600 kg |
Dimension (H x W x L) | 2,000 (H) x 970 (W) x 5,000mm (L) |
1. 제품 접촉부는 스테인리스 스틸 사용
2. GMP 디자인 채택
3. 기계 정지시 접착 상부가 제품 보호 및 필름 수축 방지를 위해
접착 상부가 자동상승 (1”)
4. 컨트롤박스를 전면에 배치하여 공간활용도를 높임
5. 관절형 PLC 터치스크린을 통한 효율적인 작업자의 조작과 동선
6. 자동 충전장치 등 옵션장비를 장착할 수 있는 제품충전구간 확보
7. 이송부의 서보 모터 적용으로 보다 세밀하고 쉬운 조작 가능
8. 블로잉 성형과 플러그 성형이 가능
1. Contact with products parts are consists of stainless
2. Fully complied GMP design
3. Automatically lift upper-sealing part when machine stop for product protection and prevent film contraction (1“)
4. Placed the control box at the front side to increase space occupancy
5. Efficient control & moving line to operator via Articulating PLC
touch screen
6. Secured space to install charging equipment in product filling
section
7. Applying servo motor in Draw-off section to easy & accurate control
8. Possible to blowing and plug forming
